MODEL 90 Modular
WOOD-FIRED OVEN
Concrete Block Assembly
43.500”
56.000”
4
8
.0
0
0
”
OVEN OUTSIDE DIAMETER
1” CLR. FROM
COMB.MATERIALS
1
”
C
L
R
.
F
R
O
M
C
O
M
B
.M
A
T
E
R
IA
L
S
36.000”
27.000”
1
0
.0
0
0
”
4.000”
4” CONCRETE
BLOCK
8” CONCRETE
BLOCK
10” X 36” HEARTH MANTLE
(STANDARD)
Top View
