Model

CS-305

CS-346

CS-440

CS-520

CS-670

CS-8000

Engine Displacement (cc)

30.1

33.4

45

50.1

66.7

80.7

Carburetor

Diaphragm

Diaphragm

Diaphragm

Diaphragm

Diaphragm

Diaphragm

w/Purge Pump

w/Purge Pump

Pro-Fire

®

Electronic Ignition

Standard

Standard

Standard

Standard

Standard

Standard

Oiling System

Automatic

Automatic

Automatic

Automatic

Automatic and

Automatic and

Manual Override

Manual Override

Chain Brake

Standard

Standard

Standard

Standard

Standard

Standard

Standard Bar Length (in)

14

16

18

20

24

24

Optional Bar Lengths (in)

12

12, 14

16, 20

16, 18

16, 20, 27

20, 27, 32, 36

Fuel Capacity (oz)

9.3

9

15.9

20.3

22.5

28.9

Oil Capacity (oz)

5.4

5.2

9.5

9.5

13

14.1

Dry Weight (lb)*

7.5

7.5

10.5

10.8

14.3

16.5

Vibration Reduction System

Standard

Standard

Standard

Standard

Standard

Standard

*without bar and chain

Chain Saw Specifications

© 2004 Echo, Inc. All rights reserved

www.echo-usa.com

Printed in the U.S.A. #5M01A00059

CS-305

The CS-305 chain saw features rear handle control
and 30.1 cc of power at an unbelievable value.

30.1 cc clean-burning 2-stroke engine.

Standard 14" bar and chain with tip guard included.

Optional 12" bar and chain available.

Automatic adjustable oiler.

Inertia-type chain brake.

Weighs 7.5 lb (power head only).

Fuel capacity: 9.3 fl oz; oil capacity: 5.4 fl oz.

CS-346

This light-weight and powerful, rear handle
commercial-grade saw received the Consumer’s
Digest “Best Buy” award.

33.4 cc clean-burning 2-stroke engine.

Standard 16" bar and chain with tip guard included.

Optional 12" and 14" bars and chains available.

Side access chain tensioner.

Automatic adjustable oiler.

Inertia-type chain brake.

Slope Advance Ignition System (SAIS2)
automatically senses engine speed and advances
ignition timing for optimum performance.

Fuel capacity: 9 fl oz; oil capacity: 5.2 fl oz.

CS-440

Fast and agile, Echo’s CS-440 chain saw features a
superior power-to-weight ratio.

45 cc clean-burning 2-stroke engine.

Standard 18" bar and chain with tip guard included.

Optional 16" and 20" bars and chains available.

Inertia-type chain brake.

Slope Advance Ignition System (SAIS2)
automatically senses engine speed and advances
ignition timing for optimum performance.

Diaphragm carburetor for smooth power flow in
any approved operating position.

Heavy-duty, cartridge-type air filter provides
unequalled filtration to help extend saw life and
maintenance intervals.

Fuel capacity: 15.9 fl oz; oil capacity: 9.5 fl oz.

CS-520

With outstanding cutting speed and power, the
CS-520 is the perfect choice for firewood cutting and
pulp operations.

50.1 cc clean-burning 2-stroke engine.

Standard 20" bar and chain with tip guard included.

Optional 16" and 18" bars and chains available.

Inertia-type chain brake.

Slope Advance Ignition System (SAIS2)
automatically senses engine speed and advances
ignition timing for optimum performance.

Heavy-duty, cartridge-type air filter provides
unequalled filtration to help extend saw life and
maintenance intervals.

High performance Pro-V vertical engine design
runs faster.

Fuel capacity: 20.3 fl oz; oil capacity: 9.5 fl oz.

CS-670

Echo’s most popular felling saw delivers excellent
speed and reliability for enhanced profitability.

66.7 cc clean-burning 2-stroke engine.

Standard 24" bar and chain with tip guard included.

Optional 16", 20” and 27" bars and chains available.

Side access chain tensioner.

Weighs 14.3 lb (power head only).

Fuel capacity: 22.5 fl oz; oil capacity: 13 fl oz.

CS-8000

Echo’s largest chain saw delivers the professional
quality, reliability and performance that you expect
for your toughest applications.

80.7 cc clean-burning 2-stroke engine.

Standard 24" bar and chain with tip guard included.

Optional 20", 27”, 32” and 36" bars and chains
available.

Automatic oiler with manual override.

Fuel capacity: 28.9 fl oz; oil capacity: 14.1 fl oz.

The professional choice

for power and reliability, all Echo chain saws are built

to tackle the toughest jobs. Whether you’re logging, felling, or limbing, each Echo saw is
designed to provide long, trouble-free life. Superior balance, outstanding control, and
vibration reduction technology make Echo chain saws a comfortable saw, but with power
to perform the task required.

CS-305

CS-346

CS-440

CS-520

CS-670

CS-8000

CS-346
