EverFocus EHD300N User Manual
Page 4
3
3. Mounting the base.
Attach the base to the wall or ceiling, fix the base by the 4 setscrews attached in the
accessory pack. Please make sure if the mounting is strengthened enough to
support it, if not, please reinforce the mounting according to the environment.
Note: The diameter of the screw hole isψ4.7mm.
Conduit plug setscrew
Side conduit entry
Back conduit entry
Mounting Setscrew
Mounting Setscrew
Figure 3
Mounting Setscrew
Mounting Setscrew
