Electrolux 726474 - Manual (Page 2)

Electrolux Benefit Cabinets
Digital freezers - 600 lt
Internet: http://www.electrolux.com/foodservice
HAEB010
2009-10-06
Subject to change without notice
REMOTE UNIT -24-15°C FOR 550/650 LT 881465
PRINTER FOR HACCP BASIC VERSION REFRIG. 881457 881457 881457 881457 881457 881457
MEAT RAIL FOR 650-1400 L REFRIGERATORS 881451
KIT TO FIT 11 PASTRY TRAYS (400X600 MM) 881031 881031 881031 881031 881031 881031
KIT INTEGRATED HACCP-DIG. REFR. (IR33) 880205 880205 880205 880205 880205 880205
KIT HACCP EKIS 922166 922166 922166 922166 922166 922166
ENERGY FREE ALARM DEVICE 881089 881089 881089 881089 881089
2/1 GN GREY "RILSAN" GRID 880720 880720 880720 880720 880720 880720
2/1 GN AISI 304 S/S GRID 881067 881067 881067 881067 881067
2 WHEELS FOR
REFRIGERATORS/REFRIG.TABLES 880539 880539 880539 880539 880539 880539
2 S/S SIDE RUNNERS FOR 600-1300L REFRIG. 880557
2 S/S RUNNERS FOR 600-650/1300-1400L.REF 881456 881456 881456 881456 881456
ACCESSORIES
2/1 GN GREY "RILSAN" GRID 3 3 3 3 4 3
2 S/S SIDE RUNNERS FOR 600-1300L REFRIG. 4
2 S/S RUNNERS FOR 600-650/1300-1400L.REF 3 3 3 3 3
INCLUDED ACCESSORIES
Power supply - V, phases, Hz 230 V, 1, 50 230 V, 1,
50
230 V, 1, 50 230 V, 1,
50
230 V, 1,
50
230 V, 1, 50
Net weight - kg. 134 134 128 134 134 134
Internal light ●
installed-electric 0.66 0.66 0.66 0.66 0.66 0.175
Power - kW
Refrigeration power - W 752 752 752 752 752 843
Refrigerant quantity - g. 270 270 270 270 270
Refrigerant type R404a R404a R404a R404a R404a R404a
N° defrost in 24 hrs. 4/30' 4/30' 4/30' 4/30' 4/30' 4/30'
N° and type of grids (included) 3, GN 2/1 3, GN 2/1 3, GN 2/1 3, GN 2/1 4, GN 2/1 3, GN 2/1
Door hinges Right Side Right Side Right Side Right Side Right Side Right Side
height 2000 2000 2000 2000 2000 2000
depth/with open doors 788, 1440 788, 1440 788, 1440 788, 1440 788, 1450 788, 1440
width 720 720 720 720 720 720
External dimensions - mm
Cooling unit Built-In Built-In Built-In Built-In Built-In Remote
Gross capacity (D.I.N. 8952) - l. 600 600 600 600 600 600
internal 304 AISI 304 AISI Stainless
Steel
Stainless
Steel
Stainless
Steel AISI
304
Scotch
Brite
304 AISI
external 304 AISI 304 AISI Stainless
Steel
Prepainted
Steel
Stainless
Steel AISI
304
Scotch
Brite
304 AISI
Type of stainless steel
Operating mode Ventilated Ventilated Ventilated Ventilated Ventilated Ventilated
Operating temperature - min/max °C -22/-15 -22/-15 -22/-15 -22/-15 -22/-15 -22/-15
TECHNICAL DATA
RS06FX1F4
726457
RS06FX1F
726318
RS06F41FS
728303
RS06FW1F
726474
RS06FX2H
726690
RS06FX1FR
727104
• Reversible self-closing door, in
positions less than 90°, with a
stop at 95° and a maximum
opening at 180°, equipped with a
magnetic door seal to guarantee
perfect closure. The pressed
stainless steel recessed door
handle without joints makes
opening the cabinet extremely
easy. All the doors are fitted as
standard with locks and keys and
a microswitch to switch off the fan
when the door is opened. • Feet with stainless steel finish.
• A wide range of optional
accessories are available.
• Extremely quiet operation at 51
Db(A).
• CFC and HCFC free.
• All models comply with the
standards required by the main
international approval bodies and
are H marked.
