Dimensions • Mål • Abmessungen • Dimensiones • Dimensions • Dimensioni
• Afmetingen • Dimensioner
Wiring schematic • Oversigt over ledningsføring • Schaltschema •
Esquema de cableado • Schéma de raccordement • Schema del cablaggio
Bedradingsschema • Schema för ledningsdragning
6.0"
15.2 cm 33.3"
84.6 cm 38.8"
98.5 cm
(4)
M6 x 15mm
4.2"
10.7 cm
5.1"
13 cm
6.0"
15.2 cm
10.1"
25.7 cm
11.5"
29.3 cm
12.8"
32.5 cm 38.8"
98.5 cm
6X
M6 x 15mm
BOSE CORPOR
AT ION, THE MOUN
TA IN, FRAMINGHAM, MA
01701-9168
MADE IN CHINA, ENGINEERED IN
THE US
A
Must be used with a BOSE Panaray System Controller or
Amplifier Card
Refer to your instruction manual for proper installation and operation procedures
.
Panara
y ® MA12EX Modula
r
Line Array Loudspeaker
COVERED BY U.S. PATENT D48006
9
4.1"
10.4 cm
5.5"
14.0 cm
PANARAY ®
MA12
PANARAY ®
MA12
PANARAY ®
MA12EX
PANARAY ®
MA12EX
NL4
+
–
NL4
NL4
+
–
NL4
NL4 wiring
loud-
speaker
loud-
speaker
thru thru
