Energizer 223 User Manual

Photo, Energizer 223, Product datasheet

background image


Classification:

"Lithium Photo"

Chemical System:

Lithium / Manganese Dioxide (Li/MnO

2

)

Designation:

IEC-CR-P2

Nominal Voltage:

6.0 Volts

Storage Temp:

-40°C to 60°C

Operating Temp:

-40°C to 60°C

Typical Capacity:

1500 mAh (to 4.0 volts)
(rated at 200 ohms at 21°C)

Typical Weight:

37 grams

Typical Volume:

24 cubic centimeters

Max Discharge:

1500 mA continuous (3500 mA pulse)

Max Rev Charge:

2 microampere

Typical Li Content:

1.15 grams

Shipping:

For complete details, please reference:

Special Provision A45 of the International

Air Transport Association Dangerous

Goods Regulations

Schedule

Drain

Load

4.0V

3.1V

2.0V

(time)

(mA)

(ohms)

(hours)

(pulses)

(pulses)

3 sec ON
7 sec OFF
3 sec ON
27 sec OFF

Specifications

(millimeters)

Industry Standard Dimensions

Typical Discharge Characteristics

Global (except US):

This battery contains a Positive Temperature

Coefficient (PTC) safety device to limit current

during short circuit conditions.

Cutoff Voltage

200

58

Simulated Application Tests

Typical Performance at 21°C

---

Continuous

1000

---

1.2

Continuous

---

---

1200

---

---

---

---

---

1500

ENERGIZER 223

This datasheet contains typical information specific to products manufactured at the time of its publication.

©Energizer Holdings, Inc. - Contents herein do not constitute a warranty.

900

---

Important Notice

---

2000

---

2.0

2.5

3.0

3.5

4.0

4.5

5.0

5.5

6.0

0

500

1000

1500

2000

2500

V

o

lt

age

, CCV

Pulses

Schedule: 3 sec ON / 27 sec OFF

Typical Drain: 900 mA

-20°C

21°C

2.0

2.5

3.0

3.5

4.0

4.5

5.0

5.5

6.0

0

300

600

900

1200

1500

V

o

lt

age

, CCV

Pulses

Schedule: 3 sec ON / 7 sec OFF

Typical Drain: 1200 mA

-20°C

21°C

PRODUCT DATASHEET

Asia Pacific Region

+852‐31026623

16.80

Reference

19.50
18.50

34.50

36.00

35.00
32.50

Form No. EBC - 8945AP

Page 1 of 1
