65BDL3550Q
13
3.2.3. Using HDMI input
HDMI Out
[HDMI IN]
HDMI1 IN HDMI2 IN AUDIO OUT
HDM3 IN
PC
3.3. Connecting Multiple Displays in a Daisy-chain Configuration
You can interconnect multiple displays to create a daisy-chain configuration for applications such as a menu board.
3.3.1. Display control connection
Connect the [RS232 OUT] connector of DISPLAY 1 to the [RS232 IN] connector of DISPLAY 2.
DISPLAY 1 DISPLAY 2
PC
[RS232 IN]
[RS232]
[RS232 OUT] [RS232 IN]
3.4. IR connection
FORMAT SOURCE
INFO LIST
OPTIONS ADJUST
VOL
NORMAL ID
ID SET ENTER
DISPLAY 1
[IR IN]
External
IR Receiver
NOTE:
This display’s remote control sensor will stop working if the [
IR IN ] is connected.
