OPERATING INSTRUCTIONS

Using the Trigger Lock

The steam cleaner has a steam trigger

lock. The steam trigger will lock when

you have pushed it all the way in.

(Fig. 3)To unlock the steam trigger, just

press it in the other direction. If you

want to have continuous steam,

depress the steam trigger and then

push in the steam trigger lock.

3. Bring the velcro strips

that are on the

back side of the

steam pocket towel

over the steam pocket

frame and attach to

the inside of the

front side of the

steam pocket towel.

(Fig. 10)

NOTE: When replacing the steam pocket

towel, make sure that the steam pocket

frame has been allowed to cool before

removing or attaching a new steam

pocket towel.

Nylon Bristle Brush (x2)

It is best for cleaning grout in-between

the ceramic and marble tiles.

To use: Attach the nylon

bristle brush on to the end

of the concentrator, which

then may be used directly

on the hand grip or with extension

tubes.

Allow the unit to cool for 15 minutes

before changing accessories.
Window Squeegee

This attachment is very useful for

cleaning large windows, plastic material,

ceramic, tiled or marble surfaces.

IMPORTANT:

When cleaning

windows, always avoid any sudden

changes in temperature to prevent glass

breakage or cracks.
To use: Connect the tile

squeegee to the hand

grip or use with

extension tube for

hard to reach surfaces.

Apply steam abundantly, rub with the

soft spongy edge, then remove excess

water and dirt with the glass wiping

edge.

Fig. 6

Locking Button

Hand Grip

Fig. 5

Attaching the Steam Pocket Towel
to the Frame

1. Slide the steam

pocket towel over

the steam pocket

frame. (Fig. 8)

2. Bring the towel all

the way to the top

of the steam

pocket frame.

(Fig. 9)

WARNING:

Always insure the

unit is “UNPLUGGED” from the

wall receptacle prior to attaching

or removing accessories.

Fig. 8

Fig. 9

Fig. 10

Care & Maintenance of the Steam
Pocket Towel

Due to the unique cleaning ability of this

cloth, proper care of your microfiber towel is

required to ensure long life and continued

cleaning ability.

• The first thing you should do when

you get a new microfiber towel is to

wash and dry it. During the manufacturing

process the fabric has a tendency to

become flat as it picks up contaminants

from the air and machinery. There will

also be a number of loose threads that,

while they cause no harm, can be

annoying the first time you use the towel.

• To clean the towel, simply wash it in your

washing machine using the warm water

setting.

• Always wash your towels separately from

other fabrics. They have a tendency to

pick up lint and other particles from other

fabrics and the next time you use your

towel, this lint will transfer to the surface

being cleaned.

• ONLY USE LIQUID DETERGENTS, never

use dry detergents as many times the

granules do not fully dissolve and become

trapped in the towel. This can scratch the

surface that you are cleaning.

• NEVER USE BLEACH OR FABRIC

SOFTENERS! Bleach will damage the

microfiber fabric and fabric softeners

deposit a coating on the microfiber fabric

that will not allow the cloth to clean

efficiently.

Concentrator

Attach the concentrator

to the handgrip or to the

extension tubes.

Attaching the Accessories to the

Flexible Steam Hose

• Air dry the towel. Do not put in a clothes

dryer as high heat will cause the towel to

shrink and the microfibers to break down.

• If you wash your towel on a regular basis

and don’t let them get too dirty, they will

last much longer. As with any fabric, dirt

particles, grease and other contaminants

can cause the fibers to break down,

therefore regular cleaning will help

preserve your microfiber towels.

• As you use the microfiber towel, you will

notice that sometimes a thread will loosen

or pull out. This is normal and you should

NEVER PULL AT THE LOOSE THREAD!

Pulling the thread can cause the weave to

come undone. Instead, simply trim the

thread with a pair of sharp scissors.

Fig. 7

NOTE:

Fit the steam pocket frame with

the angle adapter onto the extension

tube.

Step 2. If the angle adapter is not

attached to the steam pocket

frame, attach as follows: Hold

the steam pocket frame in one

hand and the

angle adapter in the

other. Insert the

angle adapter

stem into the

opening of the

steam pocket

frame as shown in

Fig. 7. Note that the flat on the

nozzle must face toward the

side of the frame with the brass

pin. Once inserted, rotate it 90°

Step 3. Insert the electrical power cord

into the outlet. Heating time is

approximately 8-10 minutes with

cold water. Filling the steam

generator with hot water will

shorten the heat up time.

Fig. 3

Using Your Steam Cleaner with
Steam Pocket

Step 1: Connect one of the extension

tubes to the hand grip on the

flexible steam hose. To

attach the extension tubes

one onto the other or onto the

hand grip, press the locking

button ensuring that it fits into

the hole. (Fig. 5, Fig. 6) To

disconnect, repeat the

operation by pressing the

locking button and pulling the

two sections apart.

Using the Variable Steam
Feature

Your steam cleaner has a variable

steam feature that allows you to adjust

the steam flow to the job that you are

doing. The variable steam control is

located on the handgrip. To increase

the steam flow, turn the knob counter

clockwise and to decrease, turn it

clockwise. (Fig. 4)

Fig. 4

WARNING

: This appliance is

under pressure. After every use,

unplug the unit and press the

steam trigger button until all

pressure has been released

before removing safety cap.

Allow unit to cool for fifteen (15)

minutes before refilling.
