EVO REV 400 ELLIPTICAL TRAINER
Visit us at: www.evofitness.com
6
PARTS LIST
No. Description Qty. Order No. No. Description Qty. Order No.
59 Front Frame Cover - Upper 1 REV400-59 89 M10 Nylon Nut 2 REV400-89
60 Front Frame Cover - Lower 1 REV400-60 90 M12 Nut 1 REV400-90
61 Crank Disk Axle 1 REV400-61 91 ID 8mm Curve Washer 4 REV400-91
62 Crank Disk Support Bushing 2 REV400-62 92 10 x 22 x 2mm Washer 2 REV400-92
63 Bearing 6005zz 2 REV400-63 93 10 x 15 x 1.5mm 2 REV400-93
64 Bearing 6400zz 4 REV400-64 94 M4 x 40mm CAP Screw 1 REV400-94
65 Strengthen Wheel Adjusters Set 1 REV400-65 95 M4 x 19mm Hard Screw 32 REV400-95
66 Rear Stabilizer Cap 2 REV400-66 96 M4 x 19mm Screw 5 REV400-96
67 Rear Stabilizer Cushion 2 REV400-67 97 M4 x 12mm Screw 8 REV400-97
68 Caster 2 REV400-68 98 M10 Head Nut 2 REV400-98
69 Front Cover 1 REV400-69 99 Frame 1 REV400-99
70 Frame Outside Cover - Left 1 REV400-70 100 M4 x 50mm Bolt 1 REV400-100
71 Frame Inside Cover - Left 1 REV400-71 101 ID 10mm Curve Washer 2 REV400-101
72 Frame Inside Cover - Right 1 REV400-72 102 M4 x 15mm Hard Screw 8 REV400-102
73 Frame Outside Cover - Right 1 REV400-73 103 Upper Computer Wire 1 REV400-103
74 M8 x 15mm Allen Head Bolt 26 REV400-74 104 Lower Computer Wire 1 REV400-104
75 M8 x 20mm CAP Screws 2 REV400-75 105 M6 x 20mm Bolt 4 REV400-105
76 M8 x 90mm Allen Head Bolt 4 REV400-76 106 Lower Hand Pulse Wire 1 REV400-106
77 M8 x 60mm Allen Head Bolt 2 REV400-77 107 Water Bottle 1 REV400-107
78 M10 x 90mm Bolt 2 REV400-78
79 M8 x 80mm Allen Head Bolt 2 REV400-79
80 M8 x 15mm Bolt 6 REV400-80
81 M10 x 45mm Allen Head Bolt 2 REV400-81
82 M10 x 45mm Screw 2 REV400-82
83 M6 x 20mm Allen Head Bolt 8 REV400-83
84 M6 x 15mm Screw 4 REV400-84
85 Fixing Inserts 12 REV400-85
86 M6 Nylon Nut 8 REV400-86
87 M8 Nylon Nut 5 REV400-87
88 M14 Nut 2 REV400-88
