WyreStorm Essentials HDMI Female to HDMI Female Coupler - Manual

1x EXP-HDMI-CPL HDMI to HDMI Coupler
In the Box
The EXP-HDMI-CPL is perfect for scenarios where the embedded HDMI
cable is not long enough and the cable cannot be replaced with a longer
cable.
Introduction
Specifications
Key Features
• Connects 2 HDMI cables together for longer transmission distance
• Bidirectional support of up to 4K@60 4:4:4 transmission
Copyright © 2020 WyreStorm Technologies | wyrestorm.com
EXP-HDMI-CPL Specification Sheet | 200407
UK: +44 (0) 1793 230 343 | ROW: 844.280.WYRE (9973)
[email protected]
1 of 2
WyreStorm - Powerful. Reliable. Simple.
HDMI to HDMI Coupler
HDMI Jack (Female) to HDMI Jack (Female)
EXP-HDMI-CPL Specification Sheet
Audio and Video
Input
1x HDMI: 19-pin type A Female
Output 1x HDMI: 19-pin type A Female
Output Video Encoding Uncompressed
Encoding Data Rate 18 Gbps
End to End Latency Zero
Audio Formats 2ch PCM | Multichannel: LPCM and Up to DTS-X and Dolby Atmos
Video Resolutions (Max)
1920x1080p @240Hz 8bit RGB
2560x1440p @120Hz 8bit RGB
4096x2160p @60Hz 10bit HDR 4:2:0
4096x2160p @60Hz 12bit HDR 4:2:2
4096x2160p @60Hz 10bit HDR 4:4:4
4096x2160p @60Hz 10bit RGB
Supported Standards DCI | RGB | HDR | HDR10 | Dolby Vision | HLG | BT.2020 | BT.2100
Maximum Pixel Clock 600MHz
Communication and Control
HDMI
TMDS | HDCP 2.2 | EDID
Supported Functions Ethernet | Audio Return Channel (ARC) | CEC | Auto Low Latency Mode (ALLM) | Variable Refresh Rate (VRR)
Environmental
Operating Temperature
32°F ~ 113°F (0°C ~ 45°C) | 10% ~ 90%, non-condensing
Storage Temperature -4°F to ~ 140°F (-20°C ~ +60°C) | 10% ~ 90%, non-condensing
Maximum BTU N/A
Dimensions and Weight
Height
11.8mm/0.5in
Width 23.5mm/0.9in
Depth 29.6mm/1.2in
Weight 0.01kg/0.02lbs
Regulatory
Safety and Emission
CE | FCC | RoHS | RCM | EAC
Female HDMI port for
Connection of an HDMI Cable
Female HDMI port for
Connection of an HDMI Cable
