Technical Information
Product
Title NL4MPXX-UC
Gender male
Electrical
Contact resistance ≤ 2 m Ω
Dielectric strength 2.8 kVac
Insulation resistance >0.1 G Ω (after dampheat)
Rated current per contact 30 A rms continuous
Rated voltage 250 V ac
Attention speakON is NOT to be used as an AC mains or power supply
connector!
Mechanical
Lifetime > 5000 mating cycles
Termination ¼" at tabs
Locking device Quick Lock
Mounting direction Rear (e.g. MFD) / front mounting
Chassis shape D
Layout standard hole position, thru holes
Material
Contact plating Ag
Contacts Copper Alloy
Shell Polyamide (PA 66)
Environmental
Temperature range -30 °C to +80 °C
Flammability UL 94 V-0
