NL PURE / EN NL PURE / EN
3.3 DIOPTER ADJUSTMENT
To ensure optimum image quality, adjust the focus to com-
pensate for any differences between your left and right eye.
How to adjust if both eyes have equal vision
If you can see equally well with both eyes, make sure the
diopter adjustment is set to zero. You can feel the protrusion
on the adjusting ring engage in the zero position and the
scale on the back of the binoculars corresponds to the index.
How to adjust if your eyes are different strengths
Look through the left eyepiece with your left eye. Select an
object and rotate the focusing wheel until it is sharply focused.
Now look at the same object through the right eyepiece with
your right eye and adjust the diopter adjustment wheel until
it is sharp.
3.4 ADJUSTING THE FOCUS
Turning the focusing wheel allows
you to focus on any object from the
shortest focusing distance (see techni-
cal data sheet) to infinity.
4. REMOVING THE OBJECTIVE
LENS COVER
1. Open the objective lens cover.
2. Pull the lens cover firmly down-
wards.
3. Fit the filler piece into the metal
ring. When you hear a click, this
means that it is attached.
Note:
When you want to replace the lens cover, slide the filler piece
out of the metal ring with your thumb and then repeat Step 3
with the lens covers.
5. GENERAL INFORMATION
5.1 SERIAL NUMBER
You will find the serial number of
your NL Pure binoculars on the back
under the diopter adjustment.
