Nikon NIKKOR Z 800mm f/6.3 VR S Lens - Manual (Page 12)

12 13 11
L-Fn2 buttons
Press to perform a function assigned using the camera. For more
information, see the description of [Custom control assignment],
[Custom controls], or [Custom controls (shooting)] in the documentation
provided with the camera. There are four buttons positioned around the
lens at 90º intervals.
Lens rotation indices
Use when rotating the camera to shoot in landscape (“wide”) or portrait
(“tall”) orientation. There are four indices positioned around the lens at 90º
intervals.
0 “Using the Tripod Collar Ring” (p.30)
Tripod collar ring rotation indices
Use when rotating the camera to shoot in landscape (“wide”) or portrait
(“tall”) orientation. There are three indices positioned around the lens at
90º intervals.
0 “Using the Tripod Collar Ring” (p.30)
Parts of the Lens: Names and Functions
12
11
12
13
