Getting Started
1-7 1-6
1 Power Jack
2
USB 3�2 Gen 1 Type-B Upstream Port
For USB Upstream Cable�
IMPORTANT
Check the package for USB Upstream
Cable and connect it to the PC and
monitor� Once this cable is connected,
the USB Type A Downstream Ports on
the monitor will be ready for use�
To Monitor
To PC
3
USB 3�2 Gen 1 Type-A Downstream Port
4 USB 3�2 Gen 1 Type-A Downstream Port
5 DisplayPort
6
HDMI Port
7
HDMI Port
8
USB Type-C Port
This port supports DisplayPort Alternate (DP Alt) Mode and up to 5V/3A
(15W) power delivery� It only carries video signals and doesn’t support data
transmission function�
9 Headphone Jack
10
Navi Key
11 Kensington Lock
12 Power Button
13
MSI Macro Key
To activate Gaming OSD�
