MSI MAG325CQRF-QD 31.5" 1440p 170 Hz Curved Gaming Monitor - Manual (Page 8)

8
Getting Started
1
Power LED
Lit in white after the monitor is turned on. If no signal input, the LED will
turn into orange. Lit in orange when the monitor is in Stand-by mode.
2
Macro Key
To activate OSD Application.
3 Navi Key
4 Power Button
5 Cable Routing Hole
6 Kensington Lock
7 Power Jack
8
DisplayPort
Supports 2560x1440@170Hz as specified in DisplayPort 1.2a.
9 HDMI™ Connector
Supports HDMI™ CEC, 2560x1440@144Hz as specified in HDMI™ 2.0b.
10 HDMI™ Connector
Supports 2560x1440@144Hz as specified in HDMI™ 2.0b.
11
USB Type-C Port
This port supports DisplayPort Alternate (DP Alt) Mode and up to 5V/3A
(15W) power delivery.
⚠
Important
Your USB-C signal source and cable must support DisplayPort Alternate
Mode to enable video output to the monitor.
12 Headphone Jack
