Chapter 3 Reference information 3-1
Chapter 3 Reference information
This section contains monitor specifications, instructions to manually install the monitor driver,
troubleshooting information, and service information.
Monitor specifications
Table 3-1. Monitor specifications
Dimensions Height 493.9 mm (19.4 in.)
Depth 199.7 mm (7.86 in.)
Width 522.1 mm (20.56 in.)
Weight Unpacked 5.24 kg
Stand
Tilt range Range: -5°/+23.5°
Swivel Range: -45°/+45°
Lift Range: 155 mm
Pivot Yes (clockwise 90° &
anticlockwise 90°)
VESA mount Supported (GS & UL Approved) 100 mm (3.94 in.)
Image Viewable image size 584.2 mm (23.0 in.)
Maximum height 286.4 mm (11.27 in.)
Maximum width 509.1 mm (20.04 in.)
Pixel pitch 0.265 mm (0.0104 in.) (V)
Response time Off: 14 ms
Normal: 6 ms
Extreme: 4 ms
Power input Supply voltage 100-240 VAC, 50/60 Hz
current 1.5A
Power consumption
Note: Power consumption
figures are for the monitor
and the power supply
combined.
Max Consumption 48 W
Typical Consumption 15 W
Standby/Suspend ＜ 0.5 W
Off
＜
0.3 W
Video input (VGA) Input signal VGA
Horizontal addressability 1920 pixels (max)
Vertical addressability 1080 lines (max)
Clock frequency 150 MHz
Video input (DP) Input signal DP
Horizontal addressability 1920 pixels (max)
Vertical addressability 1080 lines (max)
Clock frequency 180 MHz
