32
Installation
instructions
Technical data
Appliance dimensions
Cut-out dimensions
Cooking zones
Connection values
Important! The new appliance should
only be installed and connected up by
qualified and approved personnel.
Please observe these instructions,
otherwise the guarantee will not cover
any damage that may occur.
Width 590 mm
Depth 520 mm
Height 47 mm
Width 560 mm
Depth 490 mm
Corner radius R5
Position Diameter Power
front left 120/175/210
mm
800/1600/
2300 W
back left 145 mm 1200 W
back right 170x265 mm 1500/2400 W
front right 145 mm 1200 W
Connection voltage 230 V
~ 50 Hz
Total connected load max. 7.1 kW
