Echo SRM-225SB User Manual
Page 11
REMARKS
DESCRIPTION
QTY
PART NUMBER
ITEM
CARBURETOR -- RB-K93
1
A021001690
ROTOR COVER ASY
1
P005002050
1
SCREW, ROTOR COVER ASY
3
12534413931
2
SCREW, ROTOR COVER
1
12534452130
3
SWIVEL
1
P005001240
4
E-RING
1
P005000190
5
SCREW, THROTTLE ADJUST
1
P005000100
6
O-RING
1
P005000280
7
NOT AVAILABLE SEPARATELY
BODY, CARBURETOR
1
------------------
8
CAP, LIMITER
1
P005001270
9
NEEDLE - HIGH SPEED
1
P005001260
10
PURGE BASE ASY
1
P005001890
11
SCREW, PURGE BASE ASY
1
P005000270
12
BULB, PURGE
1
12538108660
13
RETAINER, PURGE BULB
1
P005000250
14
SCREW, PURGE BULB RETAINER
4
P005001900
15
COVER, DIAPHRAGM
1
12534252130
16
SCREW, DIAPHRAGM COVER
2
12534452130
17
SCREW, METERING LEVER PIN
1
12533942030
18
INCLUDES ITEMS 20-29
REPAIR KIT
1
P005001670
19
ROLLER, GUIDE
1
P005001000
20
PIN, METERING LEVER
1
------------------
21
VALVE, INLET NEEDLE
1
------------------
22
LEVER, METERING
1
------------------
23
SPRING, METERING LEVER
1
------------------
24
STRAINER
1
------------------
25
DIAPHRAGM, PUMP
1
------------------
26
GASKET, PUMP
1
------------------
27
GASKET, METERING
1
------------------
28
DIAPHRAGM, METERING
1
------------------
29
INCLUDES ITEMS 31-34
DIAPHRAGM/GASKET KIT
1
P005001660
30
DIAPHRAGM, PUMP
1
------------------
31
GASKET, PUMP
1
------------------
32
GASKET, METERING
1
------------------
33
DIAPHRAGM, METERING
1
------------------
34
99922200782
- 11 -
REVISED 04/22/09
SRM-225SB Split Shaft Trimmer
Carburetor -- RB-K93
