StarTech.com VGA to HDMI Converter and Scaler - Manual (Page 3)

Technical Specifications
Warranty 2 Years
Audio Yes
Converter Type Scaler
Output Signal HDMI
Audio Specifications 2-Channel Stereo audio (3.5mm)
7.1-channel surround sound audio (SPDIF)
Maximum Analog Resolutions 1920 x 1200
Supported Resolutions
Widescreen(16/32 bit):
1920x1200, 1920x1080, 1680x1050, 1366x768, 1280x800, 1280x768, 1280x720
Standard(16/32 bit):
1600x1200, 1400x1050, 1280x1024, 1024x768, 800x600, 640X480
Wide Screen Supported Yes
Connector A 1 - VGA (15 pin; High Density D-Sub) Female Input
Connector A 1 - 3.5mm Mini-Jack (3 Position) / Mini-Toslink (SPDIF; Optical) Female Input
Connector A 1 - Toslink (SPDIF; Optical) Female Input
Connector B 1 - HDMI (19 pin) Female Input
Connector B 1 - 3.5 mm Mini-Jack (3 Position) Female Output
Connector B 1 - Toslink (SPDIF; Optical) Female Output
Color Black
Enclosure Type Steel
Product Height 1.2 in [30 mm]
Product Length 4.1 in [105 mm]
Product Weight 21.6 oz [612 g]
Product Width 3 in [76 mm]
LED Indicators 1 - Power LED
Center Tip Polarity Positive
Input Current 600 ma
Input Voltage 110 ~ 240 AC
Output Current 2.6 A
Output Voltage 5 DC
Power Source AC Adapter Included
Humidity 20~90% RH (non-condensing)
Operating Temperature 0°C to 40°C (32°F to 104°F)
