StarTech.com 3-in-1 DisplayPort to VGA/DVI/HDMI Travel Converter (Black) User Manual
Page 2
Technical Specifications
Warranty
2 Years
Converter Type
Passive
Adapter Style
Adapter
Audio
Yes
Output Signal
DisplayPort
Output Signal
HDMI
Connector A
1 - DisplayPort (20 pin) Male
Connector B
1 - DVI-D (25 pin) Female
Connector B
1 - HDMI (19 pin) Female
Connector B
1 - VGA (15 pin; High Density D-Sub) Female
Maximum Analog
Resolutions
1920x1200/1080p
Maximum Digital
Resolutions
1920x1200/1080p
Wide Screen
Supported
Yes
Audio
Specifications
5.1 Surround Sound (Video source and destination dependant)
Note
Only one video output is supported on the video adapter at a time. If multiple connections are
made, only one of the outputs will function.
Operating
Temperature
0°C to 70°C (32°F to 158°F)
Storage
Temperature
-10°C to 80°C (14°F to 176°F)
Humidity
10~85% RH
Shipping (Package)
Weight
0.2 lb [0.1 kg]
Included in Package 1 - DisplayPort to HDMI/VGA/DVI Adapter
Included in Package 1 - Installation Guide
