StarTech.com Male VGA to Dual Female VGA Video Splitter Cable (1', Black) User Manual
Page 2
Technical Specifications
Warranty
Lifetime
Number of
Conductors
15
Connector
Plating
Gold
Cable Jacket
Type
PVC - Polyvinyl Chloride
Cable Shield
Type
Aluminum-Mylar Foil with Braid
Fire Rating
CMG Rated (General Purpose)
Connector A 1 - VGA (15 pin; High Density D-Sub) Male
Connector B 2 - VGA (15 pin; High Density D-Sub) Female
Color
Black
Wire Gauge
28 AWG
Max
Connector
Dimension
1.6 in [41 mm]
Cable Length 1 ft [0.3 m]
Cable OD
0.4 in [9 mm]
Product
Weight
5.1 oz [145 g]
Note
This product will split your video signal to deliver two identical images of the same resolution. It
cannot be used to span an image across two displays, or to show different images on each display.
Shipping
(Package)
Weight
5.3 oz [150 g]
Included in
Package
1 - 1 ft VGA to 2x VGA Video Splitter Cable – M/F
