Introduction
Packaging Contents
1 x ST121UTPEP Transmitter Unit
•
1 x ST121UTPEP Receiver Unit
•
1 x Power Adapter
•
1 x Installation Bracket
•
1 x Instruction Manual
•
System Requirements
VGA capable output on video source
•
VGA capable monitor/display
•
Installation
Hardware Installation
Turn off the PC and remote display.
1.
Connect the ST121UTPEP Transmitter unit’s “VGA In” connector
2.
with a standard VGA (DE-15) male to male cable to PC video card.
Connect the ST121UTPEP Transmitter and ST121UTPEP Receiver
3.
units together with a straight through Cat5e cable.
Connect the ST121UTPEP Receiver unit’s “VGA Out” connector with
4.
a standard VGA (DE-15) male to male cable to the monitor/display.
Connect the power adapter to either the Transmitter unit or Receiver
5.
Unit, whichever is more convenient.
It is not necessary to have
power connected to both.
Turn on the monitor and PC.
6.
