StarTech.com ST122HDMI2 2 Port High Speed HDMI Video Splitter and Signal Amplifier User Manual
Page 3
Technical Specifications
Warranty
2 Years
Audio
Yes
Ports
2
Maximum Cable Length
49.2 ft [15 m]
Maximum Digital Resolutions HDTV 1080p
PC Resolution 1920x1200
Wide Screen Supported
Yes
Connector A
1 - 3.5 mm Mini-Jack (3 Position) Female
Connector A
1 - HDMI (19 pin) Female
Connector B
2 - 3.5 mm Mini-Jack (3 Position) Female
Connector B
2 - HDMI (19 pin) Female
Color
Black
Enclosure Type
Steel
Product Height
1 in [25 mm]
Product Length
7.2 in [183 mm]
Product Weight
13.4 oz [380 g]
Product Width
3.1 in [80 mm]
LED Indicators
3 - Port Power/Input - Green indicates connection, Blue indicates activity
Center Tip Polarity
Positive
Input Voltage
Universal 115 ~ 230 AC
Output Current
2.6A
Output Voltage
5 DC
Power Source
AC Adapter Included
Humidity
0~80% RH
Operating Temperature
0°C to 40°C (32°F to 104°F)
Storage Temperature
-20°C to 60°C (-4°F to 140°F)
Shipping (Package) Weight 1.5 lb [0.7 kg]
Included in Package
1 - HDMI Splitter
Included in Package
1 - Universal Power Adapter (US/UK/EU)
Included in Package
1 - Instruction Manual
www.startech.com
1 800 265 1844
