Gas cooktop installation instructions
GAS COOKTOP INSTALLATION INSTRUCTIONS
1
A
B
C
E
J
G
H
D
F
INSTALLATION AND SERVICE MUST BE PERFORMED BY
A QUALIFIED INSTALLER.
IMPORTANT: SAVE FOR LOCAL ELECTRICAL INSPECTOR'S USE.
READ AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
318201475 (0710) Rev. D
English - pages 1-8
Español - páginas 9-16
Français - pages 17-23
Wiring Diagram page - 24
If the information in this manual is not followed exactly, a fire or explosion may result causing
property damage, personal injury or death.
FOR YOUR SAFETY:
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use any phone in your building.
•
Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
•
If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the gas supplier.
NOTE: Wiring diagrams for this cooktop are enclosed in this booklet
Figure 1
Gas Cooktop Dimensions
Gas Cooktop Cutout
Dimensions
30"(76.2 cm)
Min.*
4" X 4" (10.2 cm x 10.2
cm) opening to route gas
supply.
2"(5.1 cm) Dia.
Opening to route
power cable
For Standard
Installation:
1" (2.5 cm)
2"(5.1 cm)
7
1
/
4
"
(18.4 cm)
3"(7.6 cm)
2
1
/
2
"
(6.4 cm)
All dimensions are stated in inches and (cm).
CUTOUT DIMENSIONS
J. DEPTH BELOW
MODEL
A. LENGTH
B. WIDTH
C. DEPTH
LENGTH
WIDTH
COOKTOP
D**
E**
F
G
H
36 (91.4)
35
7
/
8
(91.1)
25 (63.5)
7¾ (19.7) 35
15
/
16
(91.3)
35
3
/
16
(89.4) 35
1
/
8
(89.2) 22 (55.9) 1
1
/
8
(2.9) Max.
7
1
/
2
(19.1)
30 (76.2)
29
7
/
8
(75.9)
25 (63.5)
7¾ (19.7)
29
15
/
16
(76)
29
3
/
16
(74.1) 29
1
/
8
(74)
22 (55.9) 1
1
/
8
(2.9) Max.
7
1
/
2
(19.1)
* 30" (76.2 cm) min. for
unprotected cabinet and
24" (61 cm) min. for cabinet
with protected bottom surface.
**Note: D & E are critical to the proper
installation of the cooktop. D reflects the
finished dimension. Due to the variation in
countertop materials, it is recommended to first
undercut this dimension, and then adjust it
upon installation of the cooktop.
