Design Wash 250
©Elation Professional • Elation Professional 6122 S. Eastern Ave. Los Angeles, Ca 90040
www.ElationLighting.com • Toll Free (866) 245-6726
DMX TRAITS
Channel 1 - Pan movement 8bit
Channel 2 - Pan fine
Channel 3 - Tilt movement 8bit
Channel 4 - Tilt fine
Channel 5 - Color wheel 1
Channel 6 - Cyan color wheel
Channel 7 - Magenta color wheel
Channel 8 - Yellow color wheel
Channel 9 - Effect wheel
Channel 10 - Zoom
Channel 11 - Shutter strobe
Channel 12 - Dimmer intensity
Channel 13 - Color macros (CMY and color wheel)
Channel 14 - Speed of CMY and dimmer
Channel 15 - Speed pan/tilt movement
Channel 16 - Lamp on/off, reset and internal programs
Product Order Code Description
Design Wash 250 250W CMY moving head wash
Accessories Order Code Description
DRC-250DS Optional road case for Design Spot 250
