Specifications are subject to change without notice.
sPeCIFICatIONs
Video input
Number/signal type ........................ 1 RGBHV, RGBS, RGsB with 1 buffered
loop-through
Connectors ..................................... 2 x 5 female BNC (5 for input,
5 for loop-through)
Nominal level .................................. 0.7 Vp-p for RGB
Minimum/maximum levels.............. 0 V to 2.0 Vp-p with no offset at unity gain
Impedance ...................................... 75 ohms
Horizontal frequency ....................... Autoscan 24 kHz to 100 kHz
Vertical frequency ............................ Autoscan 50 Hz to 120 Hz
Resolution range ............................. Autoscan 560 x 384 to 1920 x 1200
DC offset (max. allowable) .............. 2.0 V
External sync (genlock) ................... 0.3 V to 1.0 Vp-p
Video processing
Encoder .......................................... 10 bit digital
Digital sampling .............................. 24 bit, 8 bits per color
Colors ............................................. 16.8 million
Horizontal filtering .......................... 4 levels
Flicker filtering................................. 5 levels
Encoder filtering .............................. 4 levels
Video output
Number/signal type ........................ 1 RGBHV, RGBS, RGsB, or
component video
1 SDI component video (VSC 700D only)
1 S-video
1 NTSC/PAL composite video
Connectors ..................................... 5 BNC female: RGBHV/RGBS/RGsB/
component video
1 BNC female: SDI component
video (VSC 700D only)
(1) 4-pin mini-DIN female: S-video
1 BNC female: composite video
Nominal level .................................. 0.7 Vp-p for RGB
Minimum/maximum levels.............. 0.0 V to 1.0 Vp-p
Impedance ...................................... 75 ohms
sync
Input type ....................................... Autodetect RGBHV, RGBS, RGsB
Output type .................................... RGBHV, RGBS, RGsB
Genlock connectors ........................ 1 BNC female: genlock input
1 BNC female: genlock output
(terminate w/75 ohms if unused)
Standards ........................................ NTSC 3.58, PAL
Input level ....................................... 1.5 V to 5.0V p-p
Output level .................................... TTL: 5.0V p-p, unterminated
Input impedance ............................. 600 ohms
Output impedance .......................... 75 ohms
Max input voltage ........................... 5.0 Vp-p
Polarity ............................................ Negative
control/remote — scan conVerter
Serial control port ........................... RS-232 or RS-422, 9-pin
female D connector
Baud rate and protocol ................... 9600 baud, 8 data bits, 1 stop bit,
no parity
Serial control pin configurations ...... RS-232: 2 = TX, 3 = RX, 5 = GND,
9 = hard-wired IR RS-422: 2 = Tx-,
3 = Rx-, 5 = GNC, 7 = Rx+, 8 = Tx+
IR controller module ........................ VSC Remote
Program control .............................. Extron’s control/configuration program
for Windows ® Extron’s Simple
Instruction Set (SIS ™ )
general
Power ............................................. 100 VAC to 240 VAC, 50/60 Hz, 30 watts,
internal, autoswitchable
Temperature/humidity .................... Storage: -40 to +158 °F (-40 to +70 °C) /
10% to 90%, noncondensing
Operating: +32 to +122 °F (0 to +50 °C) /
10% to 90%, noncondensing
Rack mount ..................................... Yes, with optional 1U rack shelf RSU 129,
part # 60-190-01;
or RSB 129, part #60-604-01
Enclosure type ................................. Metal
Enclosure dimensions
VSC 700 ..................................... 1.75" H x 8.75" W x 10.5" D
(1U high, half rack wide)
4.4 cm H x 22.2 cm W x 26.7 cm D
(Depth excludes knobs.)
VSC 700D .................................. 1.75" H x 8.75" W x 10.75" D
(1U high, half rack wide)
4.4 cm H x 22.2 cm W x 27.3 cm D
(Depth excludes knobs.)
Product weight
VSC 700 ..................................... 2.8 lbs (1.3 kg)
VSC 700D .................................. 2.9 lbs (1.3 kg)
Shipping weight .............................. 5 lbs (3 kg)
Vibration ......................................... ISTA 1A in carton (International Safe
Transit Association)
Listings ............................................ UL, CUL
Compliances ................................... CE, FCC Class A, VCCI, AS/NZS, ICES
MTBF .............................................. 30,000 hours
Warranty ......................................... 3 years parts and labor
NOTE: All nominal levels are at ±10%.
Model Version Description Part Number
VSC 700 Standard Version ............................................ 60-477-01
VSC 700D With SDI Output............................................. 60-477-02
Included Accessories
MHR-2 SVM-F/6 Male to Female 4-pin Mini DIN
S-Video Cable, 6' ............................................ 26-542-02
Optional Accessories
BBG 6 A
Blackburst, Color Bars, and Audio Generator .. 60-535-01
VSC Remote Handheld IR Remote Control for VSC Series .... 70-206-01
SDI Output Board SDI Output Board ........................................... 70-065-02
RSU 129
1U 9.5" Deep Universal Rack Shelf Kit ............. 60-190-01
MBU 129 1U, 1/2 Rack Width Under-Desk Mount Kit
for Four-Piece Enclosure ................................. 70-219-01
RCAF-BNCM/10 RCA Female-BNC Male, Qty. 10 ...................... 100-229-01
SVHSM-BNCF 8"
(20 cm)
S-Video Male to 2 BNC Female Adapter, 8" .... 26-353-01
