Wire Short Test For Appliances
Attach clip to metal case of equipment, touch
probe to suspected wiring. If light glows, wire is
grounded and should be repaired.
Alternator Test
Check for open windings (no light glow) and
grounded coils (light glows when attached from
case coil).
Diode Test
Diode should pass current in only one direction.
Check by first using clip on case and probe at
diode end, and then reverse clip and probe. Light
should glow only in one direction.
Socket Test (Refer to Fig.2)
Make sure there is no power on the adapter.
Connect the probe tip to the adapter prong and
the alligator clip to the socket prong. The light
will turn on if there is continuity.
SPECIFICATION
Temperature
Operating: -10 ˚ C to +50 ˚ C (14 ˚ F to 122 ˚ F)
Storage : -30 ˚ C to +60 ˚ C (-22 ˚ F to +140 ˚ F)
Altitude
Operating: 3000m; Storage: 10,000m
Relative Humidity: 90%(0
˚ C-30 ˚ C);
75%(30 ˚ C-40 ˚ C); 45%(40 ˚ C-50 ˚ C)
Battery Type and Life: 2 X 1.5V AAA Size (NEDA
24G or IEC R03); 350 hours
EMC Regulations: EN50081-1, EN50082-1
