22
EN 2 / INSTALLING YOUR DISHWASHER
• BALANCING THE DOOR (LEFT
AND RIGHT)
Adjust the tension on the springs, if neces-
sary, to compensate for the weight of the clad-
ding panel. Adjust them identically on the right
and the left (Fig. 9).
The door is correctly balanced when it dopes
not fall heavily on opening and it remains hori-
zontal in the open position.
Warning:
The screw provided is intended for a
panel at least 16mm thick. If the panel is less
than 16mm thick, change the screw or shor-
ten it.
• FIXING IN THE NICHE
Fasten the dishwasher under the worktop
with the screws
(see Fig. 8) or using the
flanges you have unfolded (Fig. 3.2).
P P9 9
Fig. 8
Fig. 9
• SOUND-PROOFING SEALS
To improve the built-in appliance’s sound-
proofing, fit the sound-proofing seals (depen-
ding on the model). (
on Fig. 7)
In the case of larger spaces, glue the seal to
the panel using the adhesive strips supplied
(
on Fig. 7) P P6 6
P P6 6
Fig. 7
