Extech Instruments LASER POINTER 42530 - Manual (Page 2)

Model 42530 Version 2.4 11/05 2
Safety
• Use extreme caution when the laser pointer beam is on
• Do not point the beam toward anyone's eye or allow
the beam to strike the eye from a reflective surface
• Do not use the laser near explosive gases or in other
potentially explosive areas
Specifications
Infrared Thermometer Specifications
Range / Resolution -58 to 1000 o F (-50 to 538 o C) 0.1°C/F<200 / 1 o C/F> 200
Accuracy ± 2% of reading or ± 4 o F (2 o C) whichever is greater.
Note: Accuracy is specified for the following ambient
temperature range: 64 to 82°F (18 to 28°C)
Emissivity 0.95 fixed value
Field of View D/S = Approx. 8:1 ratio (D = distance, S = spot)
Laser power Less than 1mW
Spectral response 6 to 14
µm (wavelength)
General Specifications
Display 3½ digit backlit LCD display with function indicators
Display rate 1 second approx.
Operating Temperature 32°F to 122°F (0°C to 50°C)
Operating Humidity Max. 80% RH
Power Supply 9V battery
Automatic Power Off Meter shuts off automatically after 7 seconds
Weight 6.35 oz. / 180g
Size 8.3 x 3.5 x 1.5” (211 x 89 x 38mm)
