Important! Do not use the appliance
when extracted. Make sure the appliance is inac-
tive before extracting it. The only exception is ad-
justing the coffee mill which must be done with
the machine out (see the section "Adjusting the
coffee mill").
N.B.! Use original or manufacturer re-
commended accessories and spare parts only.
Designated use
This appliance is designed and made to prepare
coffee and heat drinks. All other use is conside-
red improper. This appliance is not suitable for
commercial use. The manufacturer is not liable
for damage deriving from improper use of the ap-
pliance. This appliance can be installed over a
built-in oven if the latter is fitted with a cooling
fan at the rear (maximum microwave power: 3
kW).
Instructions
Read these instructions carefully before using the
appliance.
•
Keep these instructions
• Failure to respect these instructions may re-
sult in burns or damage to the appliance.
The manufacturer is not liable for damage
deriving from failure to respect these in-
structions.
N.B.! The appliance has a cooling fan.
This comes on whenever coffee, steam or hot
water is delivered. After several minutes, the fan
goes off automatically.
DESCRIPTION
Description of the appliance
(page 3 - A)
A1. Cup tray
A2. Service
door
A3. Coffee guide
A4. Waste coffee container
A5. Brewing
unit
A6. Cup tray lights
A7. On-Off/stand-by
button
A8. Control panel
A9. Water softener filter (optional)
A10. Hot water and steam nozzle
A11. IEC connector
A12. Water tank
A13. Coffee spout (adjustable height)
A14. Drip tray
A15. Bean container lid
A16. Bean container
A17. Grinding adjustment knob
A18. Pre-ground coffee funnel door
A19. Measure
A20. Compartment for measure
A21. Pre-ground coffee funnel
A22. Power cable
A23. Main switch
A24. Tray
Description of the control panel
(page 3 - B)
N.B.! Only the icons relating to the con-
trols enabled for the particular function currently
being used will be lit on the touch screen.
N.B.! A light touch is enough to activate
the icon.
B1. Display: guides the user in using the ap-
pliance.
B2. SET icon to activate or deactivate menu
parameter setting mode
B3. icon rinse
B4. icon to select the coffee taste
B5. icon to select the type of coffee
(espresso, small cup, medium cup, large
cup, mug)
B6. icon to exit the selected mode
B7-B8. icons to scroll forwards or
backwards through the menu and display
the various modes
B9. OK icon to confirm the selected function
B10.
icon to deliver a cup of coffee
B11. icon to deliver two cups of coffee
B12. icon to deliver cappuccino
