12
Pos. Part Number Part Name Pos. Part Number Part Name
1 114200661 Porthole Diaphragm 28 114900269 Upper counterweight 2500 C
1 114200670 Porthole diaphragm for 2500 C 28 114900273 Upper counterweight
2 113200012 Clamp 29 113800458 Conic spring
4 119200763 Tub assy. Stainless steel 1500 30 993100001 Flat washer
4 119200811 Tub assy. Stainless steel 33 993279721 Washer
4 119200840 Tub assy. Stainless steel 2500 C 34 113200489 Clamp
4 119200857 Tub assy. Stainless steel 34 113200497 Clamp for CEE
5 119200837 Cylinder assy. 1500 35 991173005 Screw
5 119200838 Cylinder assy. 3600 36 991173008 screw
5 119200889 Cylinder assy. 2500 C 37 992400240 Nut
6 113390244 Carbon brush 38 995700012 Screw
7 114200636 Gasket 39 111901185 Support – 1500, 3600 C & 3600 CEE
7 114200616 Gasket for CEE 39 111901186 Support 2500 C
8 111600694 Back tub ring assy. 45 991173005 Screw
9 114900218 Rubber block 46 940018501 Washer
10 119200772 Cylinder cross bearing assy C-CEE 47 995700014 Screw
10 119200773 Cylin. Cross bearing assy 1000/1500C 48 995700012 Screw
10 119200844 Cylin. Cross bearing assy 2500 C 50 970230001 Clamp
11 114200638 Seal
11 114200304 Seal for CEE
12 117600244 Ball bearing 47 x 20 x 14
13 114900291 Drive belt for CEE
13 114900133 Drive belt for 1000
14 113300543 Pulley assy.
14 113300551 Pulley assy. For 2500 C
16 116190212 Motor assy. (7 terminals)
16 116190223 Motor assy. (9 terminals)
17 117600243 Ball bearing 52 x 25 x 15
18 992400243 Nut
21 113900494 Right motor support
22 113900495 Left motor support
22 113900499 Front motor support – 2500 C
24 114300707 Hose tub to filter
24 114300772 Hose tub to filter for CEE
25 113200366 Clamp
26 114900266 Front counterweight
26 114900268 Front counterweight 2500 C
TABLE 2 Oscillating group
