CMC1-75D36
ALTERATIONS REQ’D FOR A/C @ DESIGN EXTERNAL STATIC PRESSURE
COOLING UNIT HTG Speed Recommended CLG Speed
24,000 MED-LOW MED-LOW
30,000 MED-LOW MED-HIGH
36,000 MED-LOW HIGH
Speed Tap \
Static
Pressure Furnace Airflow (CFM) vs. External Static pressure (in. WC.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7
Low 817 797 773 730 668 620 555
ML 1019 995 959 918 869 821 760
MH 1257 1210 1174 1125 1076 1024 959
High 1470 1420 1366 1312 1259 1196 1127
Speed Tap \
Static
Pressure
Blower Motor Current Draw (Amps) vs. External Static pressure (in. WC.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7
Low 3.1 3.0 2.9 2.8 2.7 2.6 2.5
ML 3.9 3.8 3.6 3.5 3.3 3.2 3.1
MH 4.8 4.6 4.4 4.2 4.1 4.0 3.8
High 5.7 5.5 5.4 5.2 5.1 5.0 4.8
Speed Tap \
Static
Pressure Blower Motor Watts vs. External Static pressure (in. WC.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7
Low 312 303 298 291 280 273 264
ML 400 390 381 366 354 342 330
MH 513 490 478 462 447 432 413
High 624 605 591 573 556 542 522
Speed Tap \
Static
Pressure Temperature Rise vs. External Static Pressure (in. WC.)
0.1 0.2 0.3 0.4 0.5 0.6 0.7
Low 81 83 85 90 90 106 119
ML 65 66 69 72 76 80 87
MH 52 55 56 59 61 64 69
High 45 46 48 50 52 55 59
=
Recommended operation range
