SYMBOLS
Stay clear of the hot surface.
Stop the engine before refueling.
Check for leakage
from hose and fittings.
Shutt off fuel valve
when the engine is not in use.
HOT, avoid touching the hot area.
Read manual.
Exhaust gas is poisonous.
Do not operate in an unventilated
room or enclosed area.
Fire, open flame and smoking
prohibited.
Add oil
Engine oil
On (Run)
Engine start
(Electric start)
Engine stop
Fast
Slow
Fuel shut-off
Fuel system
failure / malfunction
Fuel (gasoline)
Choke
Battery
Off (Stop)
Plus ;
positive polarity
Minus ;
negative polarity
2. COMPONENTS
1 Spark Plug 11 Fuel Valve
2 Exhaust Outlet 12 Fuel Cup
3 Muffler Cover 13 Carburetor
4 Air Cleaner 14 P.T.O. Shaft
5 Fuel Tank 15 Oil Gauge (Oil Filler)
6 Fuel Tank Cap 16 Oil Drain Plug
7 Speed Control Lever 17 Engine Serial No
8 Recoil Starter
18 Engine Name Label
9 Starter Handle 19 Stop Switch
10 Choke Lever 20 Oil Sensor Unit
