GSM2218PB001MAN - GSM/GPRS MT-GL User Manual Page 3
Copyright 2005, Enfora L.P
1.7 Product Specifications
System Requirements Application Interface
Interface: Serial – Host DSUB 9 connector
L x W x H: 4.0 x 5.0 x 1.6 in
Housing: One Piece, seamless Aluminum
Extrusion
TX Power:
Class 4 (2W @850/900 MHz)
Class 1 (1W @1800/1900 MHz)
Slot Class: MS10(4RX/2TX, 5 MAX)
• Host Protocols:
PPP, AT Commands, UDP,
TCP/IP
• Internal Protocols: UDP, TCP/IP (future release)
• API Control/Status: AT or UDP
• Friend’s IP Feature
• Auto-Registration software upon power-up
• Over the air commands for:
- I/O Control - Status Change Reporting
- GPS TX Interval - GPS Content
- Binary Reporting - Event Reporting
- Timed Reporting
- Distance Reporting
- Alarm Reporting - Geo-Fencing
Band Operation SIM Card / Interface / I/O
GSM2218 (850/900/1800/1900)
• SMA Antenna Connector for 3.3 Vdc GPS 3.3
• External SIM accessible via end cap
• Audio connection
• TNC Antenna Connector for GSM
• 3 Pin I/O – 2 Input, 1 Output
3 LED Status indicators
1 Ignition Sense
• 1 Audio Input/Output
GPRS Packet Data Environment
Mode: Class B, Multislot 10 Certified
Protocol: GPRS Release 97, SMG 31
Coding Schemes: CS1 – CS4
Packet Channel: PBCCH/PCCCH
Operating: -30°C to +70°C
Spec. Compliant: -20°C to +60°C
Storage:
-40°C to +85°C
Humidity: Up to 95% non-condensing
GSM Functionality Status Indicator
Voice: Full Rate, Enhanced full rate and
half rate, AMR (GSM2218)
CS Data: Asynchronous, transparent and
non transparent up to 9.6 KB
GSM SMS: Text, PDU, MO/MT Cell
broadcast
• Power ON
• Registration Status
• GPS Status
• User Defined
Certification (Pending) Power
GSM2218
FCC: Part 15,22,&24 Part 15
GCF: Version 3.11.0 Version 3.5.1
PTCRB: Version 2.9.1 Version 2.7.2
Industry Canada Industry Canada
RTTE RTTE DC Voltage: 9 - 30 V
MT-GL 2218 @ 12V Avg Peak
BAND MODE (mA) (A) @ (dBM)
GSM 850& 1TX/1RX 390 0.600 @ 32.5
900 1RX 180
Idle 65
GSM 1800& 1TX/1RX 400 0.570 @ 32.0
1900 1RX 190
Idle 55
GPS Functionality Part Number
• SMA Antenna Connector for GPS
• Supports 3.3V Active Antenna
• GPS Protocols: NMEA, TAIP, Enfora binary
• Stored GPS Messages Feature
GSM2218 850/900/1800/1900
