INTRODUCTION
Installation and Operations Manual 1
Disclaimer
While every precaution has been taken in the preparation of this manual, the
manufacturer assumes no responsibility for errors or omissions. Neither
does the manufacturer assume any liability for damages resulting from the
use of the information contained herein. The manufacturer reserves the
right to change the specifications, functions, or circuitry of the product
without notice.
The manufacturer cannot accept liability for damages due to misuse of the
product or other circumstances outside the manufacturer’s control. The
manufacturer will not be responsible for any loss, damage, or injury arising
directly or indirectly from the use of this product.
System introduction
Thank you for choosing the Rose Electronics

CrystalLink
 USB 2.0 CAT5
extender. The CrystalLink USB 2.0 CAT5 extender is the result of Rose
Electronics commitment to providing state-of-the-art solutions for today’s
demanding workplace. The CrystalLink USB 2.0 CAT5 has proven to be a
valuable investment for any business, big or small, that has a need to
access and extend their USB 1.1 or 2.0 peripherals from a remote location.
This location can be up to 330 feet (100m).
The receiver unit’s USB ports connect to your USB peripherals. The
number of peripherals can be increased by using a standard USB hub.
The USB peripherals can be USB 1.1 devices (low-speed or full-speed) or
USB 2.0 high-speed devices operating up to 480 Mb/s. The receiver unit
can supply up to 500 ma per USB port for driving high-power USB devices.
Plug-and-play installation makes installing the transmitter and receiver
simple and easy. Connect the transmitter to the computers USB port,
connect the USB ports on the receiver to your USB devices, connect the
transmitter to the receiver with up to 330 feet of industry standard CAT5 or
better cable, connect the 24VDC power adapter to the Transmitter only and
power on the system. The Receiver unit receives its power via the CAT5
cable from the transmitter.
The USB devices will function normally as if they are directly connected to
your computer’s USB port even though they are up to 330 feet away.
