SPECIFICATIONS
Type EQ350
EQ250
Pickup Device
1/3'' SONY Super HAD CCD
Picture Elements
NTSC: 768(H) x 494(V)
NTSC: 510(H) x 492(V)
PAL: 752(H) x 582(V)
PAL: 500(H) x 582(V)
Video Format
NTSC or PAL
Scanning System
NTSC: 525 TV lines, 60 fields/sec
PAL: 625 TV lines, 50 fields/sec
Horizontal Resolution
560TVL
380TVL
Sensitivity 0.5Lux/F=1.2
0.3Lux/F=1.2
S/N Ratio
Over 48dB(AGC off)
Electronic Shutter
1/50(1/60)~1/100,000
Lens Type
C/CS mount
Video Drive / Direct Drive
Back Light Comp.
ON/OFF Switch
Auto Gain Control
ON/OFF Switch
Fluorescent Light
ON/OFF Switch
Auto White Balance
Yes
Gamma Correction
0.45
Video Output
BNC 1.0Vp-p , 75ohm
Sync. Mode
Line Lock/Internal Sync
Phase Control
V-Phase +/- 90°
Power Source
2 types:
100VAC~240VAC
12VDC/24VAC
Power Consumption
100VAC~240VAC: 12VA max.
24VAC: 7VA max.
12VDC: 4.5W max.
Dimensions
57mm(W) x 51mm(H) x 140.2mm(D);
2.25"(W) x 2"(H) x 5.52"(D)
Weight
0.5kg ; 1.1lbs
Operating Temperature
0°C~50°C ; 32°F~122°F (20%~80% Humidity)
Certifications FCC/CE
