4
SPECIFICATIONS
Type ECZ230E ECZ330E
Pickup Device 1/3'' SONY Super HAD CCD
Video Format NTSC or PAL
Scanning System
NTSC: 525 TV lines, 60 fields/sec
PAL: 625 TV lines, 50 fields/sec.
Picture Elements
510 x 492 (NTSC) 768 x 494 (NTSC)
500 x 582 (PAL) 752 x 582 (PAL)
Horizontal Resolution 380 TV Lines 520 TV Lines
Sensitivity
0.3 Lux/F=1.2 (AGC ON) 0.4 Lux/F=1.2 (AGC ON)
0 Lux (IR LED on) 0 Lux (IR LED on)
S/N Ratio Over 48dB (AGC off)
Electronic Shutter 1/50(1/60)~1/100,000
Lens Type
Board Lens f=4.3mm / F=2.0; f=6mm/F=2.0; f=8mm/F=2.0
*Lens models and availability vary in different regions
Back Light Comp. Yes
Auto Gain Control Yes
Auto White Balance Yes
Gamma Correction 0.45
Video Output BNC 1.0Vp-p , 75ohm
Sync. Mode Internal sync
IR Distance
4.3mm lens: 10M /33feet 6mm lens: 12M / 39 feet
8mm lens: 15M /49feet
IR Wavelength 850nm
IR LED Lifespan 20,000 hours
IR Control Vari-frequency
Weatherproof
IP66
Power Source 12VDC
Power Consumption 12VDC: 3W max.
Dimensions
With sun shield:60.5mm(W) x 59.4 mm(H) x 82mm (D) ;
2.4" (W) x 2.3"(H) x 3.2" (D)
Without sun shield:55mm(O.D.) x 60 mm(H) ;
2.2" (O.D) x 2.4"(H)
Weight 0.3 kg ; 0.7 lbs
Operating Temperature -10°C~50°C ; 14°F~122°F (20%~80% Humidity)
Certifications FCC/CE (Class A)
