Page 14 12433-5-0606
Parts can be ordered only through your service person or dealer. For best results, the service person or dealer should order parts through
the distributor. Parts can be shipped directly to the service person/dealer.
All parts listed in the Parts List have a Part Number. When ordering parts, first obtain the Model Number from the name plate on your
equipment. Then determine the Part Number (not the Index Number) and the Description of each part from the following appropriate
illustration and list. Be sure to give all this information.
Furnace Model Number
Part Description
Furnace Serial Number Part Number
Type of Gas (Propane or Natural)
Do not order bolts, screws, washers or nuts. They are standard hardware items and can be purchased at any local hardware store.
Shipments contingent upon strikes, fires and all causes beyond our control.
Empire Comfort Systems, Inc. Nine Eighteen Freeburg Ave. Belleville, IL 62222-0529
1 TH-100 WALL MOUNTING PLATE
2 TH-104 GASKET - FOR WALL MOUNTING
PLATE
3 TH-015 AIR DROP ASSEMBLY - DV-210
3 TH-018 AIR DROP ASSEMBLY - DV-215
4 11757 OUTER CASING - DV-210
4 11758 OUTER CASING - DV-215
5 TH-142 INNER CASING - DV-210
5 TH-143 INNER CASING - DV-215
6 TH-008 FRONT PANEL - DV-210
6 TH-009 FRONT PANEL - DV-215
7 TH-024 COMBUSTION CHAMBER - DV-210
7 TH-027 COMBUSTION CHAMBER - DV-215
8 712098 GASKET - OBSERVATION HOLE
COVER
9 DV-781 OBSERVATION HOLE COVER
10 DV-064 COVER PLATE - OBSERVATION HOLE
11 852098 NUT FOR ORIFICE FITTING
12 742134 BURNER ORIFICE - DV-210 NAT
12 742133 BURNER ORIFICE - DV-215 NAT
12 742297 BURNER ORIFICE - DV-210 LPG
12 742282 BURNER ORIFICE - DV-215 LPG
13 742038 ORIFICE FITTING
14 732016 ELECTRODE AND WIRE
15 722049 MANIFOLD
16 R-5598 GAS VALVE 7000 MVRLC - NAT
16 R-5599 GAS VALVE 7000 MVRLC - LPG
17 R-2890 PILOT BURNER W/ORIFICE - LPG
17 R-2893 PILOT BURNER WITH ORIFICE - NAT
18 TH-335 PILOT SHIELD
19 712051 GASKET - PILOT BURNER
20 TH-133 CHAMBER DOOR WITH GASKET
- DV-210
20 TH-134 CHAMBER DOOR WITH GASKET
- DV-215
21 TH-365 VALVE BRACKET
22 TH-336 PILOT TUBING - 1/4" (6.4mm) WITH
FERRELLS (NAT.)
22 TH-367 PILOT TUBING - 1/4" (6.4mm) WITH
FERRELLS (LP)
23 672064 THERMOPILE - GENERATOR
24 R-2708 PIEZO IGNITOR
25 TH-289 IGNITOR BRACKET
26 TH-275 BURNER - DV-210
26 TH-267 BURNER - DV-215
27 TH-109 3" (76mm) DIA FLUE OUTLET TUBE
28 TH-107 5" (127mm) DIA AIR INLET TUBE
29 TH-331 OUTSIDE MOUNTING PLATE
30 TH-334 VENT CAP
31 TH-123 VENT KIT COMPLETE
32 R-5788 WALL THERMOSTAT - MILLIVOLT
NOT SHOWN 742158 ORIFICE FOR PILOT - NAT
NOT SHOWN 742266 ORIFICE FOR PILOT - LPG
NOT SHOWN TH-300 GASKET FOR CHAMBER DOOR - DV-
210
NOT SHOWN TH-281 GASKET FOR CHAMBER DOOR - DV-
