Electrolux Dishwashing
Medical Line Hood Type
Internet: http://www.electrolux.com/foodservice
IDC010
2012-07-26
Subject to change without notice
Convertible to 230 V / 3 / 50 Hz
Supply voltage 400 V, 3N, 50
Net weight - kg. 130
Noise level - dBA <63
total power 12.1
Rinse pump 0.35
Power - kW
water consumption lt./h 8.3
Rinsing
Boiler elements - kW 10.5
Boiler capacity - lt. 12
water consumption - lt./cycle 8.3
temperature during rinse - °C 90
duration - sec. 35
Hot rinse cycle
electrical elements - kW 3
power pump - kW 1.5
tank capacity - lt. 42
temperature -°C 65
Washing cycle
height 409
depth 560
width 590
Cell dimensions - mm
height 1560
depth 756
width 735
External dimensions - mm
Door/hood thickness Double
Basket capacity/h 17
Dishes capacity/h 308
Duration cycles - sec. 210/270/390/inf
N° of cycles 4
Rinse aid dispenser ●
Automatic lifting ●
Rinse Booster Pump ●
hardness - °f 7-14
temperature - °C 50
Water supply
TECHNICAL DATA
EHTAIMLAU
504236
• The fully automatic self-cleaning
cycle avoids the risk of bacteria
proliferation.
• The self-draining wash pump
and the boiler facilitates the
evacuation of stagnant water after
long periods of inactivity to ensure
a higher level of hygiene.
• Load bearing frame height
adjustable feet, hood, tank,
washing and rinsing arms, jets and
screws in 304 AISI stainless steel
to ensure long term reliability.
• High efficiency air gap (class A)
in water inlet circuit to avoid water
being siphoned back into the
network as a result of a sudden
drop in main pressures.
• 304L stainless steel boiler with
higher welding protection
improves the resistance against
corrosion by chlorinated water.
• PVC water supply hose with
metal connections resistant to
high water pressure.
• The IPX5 water protection.
• Pre-arranged for on-site HACCP
implementation and Energy
Management device. FLEXIBILITY AND ERGONOMICS
• The incorporated Soft Start
feature offers additional protection
to delicate items such as
glassware and crockery and
increases wash pump reliability.
• Suitable to be connected to
specific pre-wash tabling, service
entry and exit tabling and roller
conveyor tabling – included in
Electrolux Professional Handling
System range.
• More ergonomic operation
thanks to the Automatic hood
lifting, with a button on the control
panel to close the hood which will
automatically open when the cycle
finishes.
• Open hood on the back side to
prevent steam blasts to the
operator.
• All machines are pre-arranged to
accept external dispensers. EASY ON THE ENVIRONMENT
• 97% recyclable by weight.
• CFC free packaging.
• Low noise level.
• Developed and produced in ISO
9001 and ISO 14001 certified
factory.
• In compliance with
H
requirements.
* Duration cycles: declared actual
cycle duration times can extend
when water supply temperature is
lower than indicated.
