EQUATOR
ADVANCED Appliances
Spare parts list :
EZ3710CEE & EZ1710V (WHITE / PLATINUM)
Page 12
Table 4 - Ventilation
Pos#
PART#
DESCRIPTION
01
00732
Fan motor-3710 / 1710
02
00807
Fusible Link (144degree)-3710 / 1710
03
00808
Thermostat -3710 / 1710
04
00825
Upper heater housing -3710 / 1710
05
00826
Upper reflecting screen WDM-3710 / 1710
06
00745
Heating element-3710 / 1710
07
00737
Gasket -3710 / 1710
08
01826
Lower reflecting screen WDM-3710 / 1710
09
00824
Clamp(heater housing & Boot) -3710 / 1710
10 10720
Condenser-3710
11
10721
Condenser gasket to tub -3710
12
10744
Hose condenser to tub-3710
13 / 14
10736
Flow valve (to condensing chamber) -3710
15
11721
Condenser gasket to heater housing -3710
16
01825
Lower heater housing -3710 / 1710
17
00733
Nut-3710 / 1710
18
01733
Impeller assembly(squirrel cage) -3710 / 1710
19 00718
Clips-3710
/
1710
