12
O
PERATION
OPERATION WITH BLADES
Preparing the Trimmer/Brush Cutter for Blade Use
WARNING DANGER
Blade use DEMANDS specific Brush Cutter configuration. Operation without specified shield and harness can result
in serious personal injury. Follow installation instructions included in optional kits.
C
A
B
D
A
C
Grass/Weed Blades Require:
Install Blade Conversion Kit - Includes
metal shield (A), barrier bar (B), and
shoulder harness (C).
NOTE
The Barrier Bar is used to restrict rearward movement of the unit. The Barrier Bar is NOT A HANDLE and should not
be gripped when using or carrying the unit.
Brush/Clearing Blades Require:
Install U-Handle / Blade Conversion Kit -
Includes metal shield (A), shoulder
harness with hip pad (C), and U-Handles
(D).
NOTE
When selecting optional Blade Conversion or Combination Blade/U-Handle Kits, only use kits that are marked for use
with the model and serial number of this unit.
