2.6.2
Hydraulic Filter is replaceable cartridge type.
P/N 513211: 10 microns, 18 psi bypass (Summer use above 32
°
F)
P/N 523541: 40 microns, 18 psi bypass (Winter use below 32
°
F)
2.6.3
Speed Range: Forward 0 - 6.2 mph (10.0 km/h)
Reverse 0 - 2.2 mph (3.5 km/h)
2.7 WHEEL DRIVE SYSTEM:
Drive wheels are direct coupled to Parker/Ross wheel drive motors with 1.0" (25.4
mm) tapered shaft.
2.8 TIRES
Drive
Front Caster
Size ......................... 16 x 6.50-8 ........................ 9 x 3.50-4
Quantity ............................. 2 ........................................ 2
Tread ....................... Turf Master ............................ Smooth
Ply Rating .......................... 4 ........................................ 4
Pressure ............... 14 psi (97 kPa) .................22 psi (152 kPa)
2.9 DECK
2.9.1
Cutting Width:
Model 36 in. .............................................35.38 in. (89.9 cm)
Model 48 in. .............................................47.24 in. (120.0 cm)
2.9.2
Discharge: Right Side
2.9.3
Blade Size:
Model 36 in. ...................18.00 in. (45.7 cm).............. Qty. 2
Model 48 in. ...................16.25 in. (41.3 cm).............. Qty. 3
2.9.4
Type of Drive: Manual engagement of belt with over-center lock. Belt tension
is adjustable via turnbuckle.
2.9.5
Blade Brake: When the blade engagement control is move to the disengaged
position a friction brake pad stops the rotation of the blades.
2.9.6
Deck Mounting: Bolted directly to the engine deck.
2.9.7
Cutting Height: Adjusts in 1/4” (.63 cm) increments from 1” (2.5 cm) to 4 1/4”
(10.8 cm).
2.10 DIMENSIONS
2.10.1 Overall Width:
36” 48”
Discharge chute down
46.1”
58.2”
(117.1 cm)
(148.0 cm)
Discharge chute up
36.4”
48.1”
(Transport only)
(92.5 cm)
(122.2 cm)
2.10.2 Overall Length:
36” 48”
Overall Length
78.0”
73.0”
(198.1 cm)
(185.4 cm)
2.10.3 Curb Weight:
36”
48”
Curb Weight
∗
433 lbs.
486 lbs.
(196 kg)
(220 kg)
∗
Weights will vary slightly depending on engine option.
2.10.4 Overall Height: 43.2”(109.7 cm)(all units)
2.10.5 Tread Width (to outside of tires):
36” Model ....................35.6” (90.4 cm)
48” Model ....................39.6” (100.6 cm
