Exmark Navigator 4500-368 - Manual (Page 20)

HOPPER GROUP (cont.)
18
Item
Part No.
Description
Qty.
1 1-303435 Washer, Spring Disk 1/4 ........................ 3
2 109-3854 Kit, Fill Sensor Wire ............................... 1
3 1-513762 Clip, Loom 1/2........................................ 4
4 1-543296 Grommet................................................ 1
5 1-303335 Tie, Plastic ............................................. 1
6 109-3955 Door, 9.5 Bushel Hopper........................ 1
7 103-5745-03 Panel, Hopper Screen............................ 1
8 109-4253 Asm, Door Pivot W/Decal (LH)............... 1
9 109-4254 Wld, Door Pivot W/Decal (RH) ............... 1
10 103-6024 Decal, Exmark Logo............................... 1
11 109-3648 Wld, Switch Mount ................................. 1
12 103-6067-03 Bracket, Motor (LH)................................ 1
13 103-6068-03 Bracket, Motor (RH) ............................... 1
14 103-7048-03 Panel, Screen Extend ............................ 1
15 109-4153-03 Wld, Door Support ................................. 1
16 103-7085-03 Plate, Switch .......................................... 1
17 103-7098-03 Handle, Screen (LH) .............................. 1
18 103-7099-03 Handle, Screen (RH).............................. 1
19 109-3650-03 Wld, Diffuser .......................................... 1
20 103-9466 Asm, Fill Sensor..................................... 1
21 109-0717 Asm, Hopper Screen.............................. 1
22 321-4 Screw, HH 1/4-20 x 3/4 .......................... 5
23 103-8203-03 Guide, Screen........................................ 2
24 1-613235 Washer .................................................. 2
Item
Part No.
Description
Qty.
25 103-8444 Decal, Pinch Point ................................. 2
26 103-8680 Deflector, Discharge Chute.................... 1
27 103-8789 Flag, Fill Sensor..................................... 2
28 109-3853 Motor ..................................................... 1
29 103-9456 Asm, Door Hopper ................................. 1
30 321-2 Screw, HH 1/4-20 x 1/2.......................... 19
31 322-4 Screw, HH 5/16-18 x 7/8 ........................ 4
32 329-4 Screw, HH 1/4-28 x 3/4.......................... 3
33 103-9457 Asm, Hopper.......................................... 1
34 3230-23 Bolt, Carriage 5/16-18 x 3/4 ................... 6
35 3250-48 Screw, PPH #10-24 x 1 3/4.................... 2
36 3256-2 Washer, 1/4 Std..................................... 17
37 9107622 Screw, PPH #6-32 x 5/8......................... 2
38 3256-23 Washer, 5/16 SAE ................................. 4
39 32122-30 Screw, Truss HD #10-24 X 1/2 .............. 2
40 109-1063 Screw, Wing 1/4-20 x 3/4....................... 3
41 3296-2 Nut, Nyloc #10-24 .................................. 4
42 3296-42 Nut, Nyloc 1/4-20 ................................... 5
43 3296-9 Nut, Nyloc #6-32 Thin ............................ 2
44 32105-32 Screw, Truss HD 1/4-20 x 1 ................... 6
45 107069 Nut, Retainer-Panel 1/4-20 .................... 5
46 32128-20 Nut, Whizlock 5/16-18............................ 8
47 32128-33 Nut, Whizlock 1/4-20 ............................. 27
48 32122-42 Screw, Truss HD 1/4-20 x 1/2 ................ 4
Reference page 18 for remainder of items included in hopper assembly.
