USING THE UNIT AS A HAND
VACUUM
• Press the telescopic tube release
button to remove the telescopic tube.
(See Fig. 2 page 4)
• Press the floor brush release button to
remove the floor brush. (See Fig. 3
page 4)
• Attach the shoulder strap to the
shoulder strap attachment point.
(Fig. 6)
• Attach the crevice tool or the dusting
brush to the end of the hose.
Crevice Tool
For radiators, crevices, corners,
baseboards and
between cushions.
Dusting Brush
The dusting brush is
used for the furniture,
venetian blinds,
books, lamp shades
and shelves.
USING THE UNIT AS AN UPRIGHT
• Unwind the power cord
and plug into the
120V outlet.
• Push down on the
locking button to adjust
the height of the
telescopic handle.
NOTE: When vacuuming
deep pile carpets or
hard to vacuum
carpets, lower the angle
of the telescopic
handle (see
illustration at
right) for
easier
maneuverability.
Lo
we
r
WARNING
After extended use, the body of the
vacuum cleaner may become hot.
When using the unit with the shoulder
strap, the unit will touch the body of
the user. Therefore, make sure that
the unit body is cool before you use
with the shoulder strap. If during use,
the vacuum gets too warm, allow it to
cool before continuing to use.
When the Intelli-Sense TM Filter
Monitor lights up, it means that the
dust cup is full or the HEPA filter,
non-woven pre-filter or debris
screen needs cleaning. You must
empty the dust from the dust cup
and clean the HEPA filter, non-
woven pre-filter and debris screen
right away.
Intelli-Sense TM Filter Monitor
Turbine
Tilt
Upwards
Locking Latch
From time to time, the turbine of your turbo
brush will require cleaning. To do this:
1. Remove the turbo brush from the hose
or telescopic extension tube.
2. Slide locking latch forward then tilt the
top housing of the brush upwards. The
top housing is hinged and will tilt up
approximately 45° only. (Fig. 8)
3. There may be some dust, lint, hair, etc
on the turbine wheel. Remove as much
of this as possible.
4. You may also use the unit’s hose with
crevice tool attached and use the
vacuum to remove any additional debris
from the turbine.
5. Ensure that the turbine wheel moves
freely by rotating it with your finger. If
the turbine does not rotate, call
Customer Service for help.
6. Once clean, close the top cover of the
turbo brush and slide the locking latch
toward the rear of the brush to lock.
To use the air driven turbo brush to
clean upholstery:
1. Remove the flexible hose from the
hose connector. (Fig. 7)
2. Push the air driven turbo brush onto
the end of the flexible hose as far as
it will go.
Cleaning Air Driven Turbo Brush
Using The Unit With Air Driven
Turbo Brush
The efficiency of your air driven turbo
brush depends on the bristle brush
rotating at high speed. Strong air suction
is needed to accomplish this. In order to
ensure that maximum air suction is
maintained, please read the following
instructions:
1. Empty the dust cup frequently.
2. Always shake out the HEPA filter, non-
woven pre-filter and Debris Screen
when emptying the dust cup container.
3. Ensure that the rotating brush is kept
free of hair and string which may
accumulate and decrease brush
performance.
4. Keep Air Driven Turbo Brush turbine
free of dirt and foreign matter. (See
illustration for cleaning instructions.)
Air Driven Turbo Brush
Attaching the Air Driven Turbo
Brush to the Flexible Hose
Telescopic Extension Tube
To use the air driven turbo brush or other
accessory with the flexible hose telescopic
extension tube:
1. Remove the flexible hose from the
hose connector.
2. Insert the top end of the telescopic
extension tube to the end of the flexible
hose.
3. Push the air driven turbo brush or other
accessory onto the end of the
telescopic extension tube as far as it
will go.
Important: In order to ensure that maximum
air suction is maintained, empty the dust cup
frequently and shake out the HEPA filter and
clean the non-woven pre-filter and debris
screen at the same time. Ensure that the
rotating brush is kept free of hair and string
which may accumulate and decrease brush
performance.
Pet Hair Removal Brush
The pet hair removal brush
is for use on upholstery,
drapes and other fabric
surfaces to remove lint, pet
hair, etc. THE PET HAIR REMOVAL
BRUSH IS NOT INTENDED TO BE
USED AS A PET GROOMING
DEVICE.
Flexible Hose Telescopic Extension
Tube
To use with all accessories
to reach hard to reach
places.
Fig. 6
Fig. 7
Fig. 8
OPERATING INSTRUCTIONS OPERATING INSTRUCTIONS
Attaching the Air Driven Turbo
Brush to the Flexible Hose
5 6
