Echo SRM-265T User Manual

Page 13

background image

REMARKS

DESCRIPTION

QTY

PART NUMBER

ITEM

FILTER, AIR

1

1

13031054130

1

PLATE, PREVENT

1

12901152730

2

SCREW 5X65

2

90024205065

3

CASE, AIR CLEANER - BLACK

1

P021004480

4

See Carburetor Diagram For Additional Information

CARBURETOR

1

------------------

5

GASKET, INTAKE

2

2

V103000270

6

PLATE, INSULATOR

1

A209000140

7

SCREW 5X25

2

90016205025

8

INSULATOR, INTAKE

1

A200000200

9

GASKET, INTAKE

2

1

V103000210

10

Footnotes

1: Also Included In REPOWER TUNE-UP KIT
2: Also Included In GASKET KIT

99922204070

- 13 -

REVISED 07/09/09

Table of Contents

Part Number Index

SRM-265T Trimmer

Intake
