C-34 E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e
Touchmonitor Specifications
Table C.1 17" LCD Touchmonitor (ET17X7L-XXWB-1) Specifications
Display Type Active matrix, thin film transistor
(TFT), liquid crystal display
Size 17-inch diagonal
337.920 x 270.336 mm useful screen
area
Pixel Format 1280 x 1024
Touchscreen 0.125-inch IntelliTouch and
AccuTouch, anti-glare
IntelliTouch or AccuTouch
Colors 16 million with dithering
Display
Brightness Non-Touch: 250 cd/m² (Typical) AccuTouch: 200 cd/m² (Typical)
Back-light Lamp
Life 50,000 hours at 50% brightness
typical
Viewing Angle Horizontal
Vertical
-75~75 or 150 degrees total
-70~70 or 140 degrees total
Contrast Ratio 400:1 typical
Display Response
Time 30 ms (tr) /15 ms (tf)
Environmental Operating Temp
Storage Temp
Humidity
0°C to 40°C
-30°C to +60°C
80% non-condensing AT
95% IT
Mechanical Weight
Size
20 lbs. maximum approx. weight
for IntelliTouch and AccuTouch
See drawings on next page.
Electrical Input Video
Input Power
Power Dissipation
VGA/SVGA/XGA /SXGA analog or digital video
Main Adapter:100-240VAC,50/60Hz /LCD:19VDC 3.42A
Universal
Agencies Safety & EMC RU and TUV-GS
FCC-B, CE, VCCI, C-Tick, ICES-03
