Introduction
Table with 2 chairs
Introduction
Before assembling and using the device
for the first time, take time to familiarise
yourself with the product first. Read the
following assembly instructions and safety instructions
carefully. Only use the product as described and
for the designated areas of application. Please keep
these instructions in a safe place. If you hand this
product on to a third party, you must also pass on
all documents relating to the product.
Proper Use
This article is intended for use as piece of furniture
in a private domestic environment only. Any use
other than that described or any modification of the
product is not permissible and may result in injury
and / or damage to the product. The manufacturer
is not liable for damage caused by improper use.
The product is not intended for commercial use.
Description of parts
1
Table leg (front)
2
Table leg (middle)
3
Table leg (back)
4
Screw (approx. ø 5.8 x 23 mm)
5
Screw (approx. ø 5.8 x 15 mm)
6
Metal angle
7
Table top
8
Shelf
9
Screw (approx. ø 5.8 x 48 mm)
10
Spring washer
11
Connecting strut 1
12
Connecting strut 2
13
Mesh panel
14
Plain washer
15
Screw (approx. ø 7.8 x 40 mm)
16
Metal basket
17
Hook for wall attachment
18
Dowel
19
S-hook
20
Screw (approx. ø 4.9 x 36 mm)
21
Allen key (approx. ø 4 mm)
22
Allen key (approx. ø 5 mm)
23
Screw (approx. ø 5.8 x 33 mm)
Included items
Please check immediately on unpacking that the
delivery is complete and that the product and all
parts are in perfect condition. Do not under any
circumstances assemble the product if the delivery
is incomplete.
1 Table leg (front)
1 Table leg (middle)
1 Table leg (back)
6 Screws (approx. ø 5.8 x 23 mm)
2 Screws (approx. ø 5.8 x 15 mm)
1 Metal angle
1 Table top
2 Shelves
12 Screws (approx. ø 5.8 x 48 mm)
14 Spring washers
2 Connecting struts 1
1 Connecting strut 2
1 Mesh panel
2 Plain washers
2 Screws (approx. ø 7.8 x 40 mm)
1 Metal basket
1 Hook for wall attachment
3 Dowels
2 S-hooks
3 Screws (approx. ø 4.9 x 36 mm)
1 Allen key (approx. ø 4 mm)
1 Allen key (approx. ø 5 mm)
2 Screws (approx. ø 5.8 x 33 mm)
2 Chairs
1 Assembly instructions
