Specifications
32
10.0 S
PECIFICATIONS
Table 6 Liebert XDR specifications
Models XDR20B1- *
XDR20B1P *
(Pre-Charged R-134a)
XDR20B1R *
Cooling Capacity, Nominal,
rated at 104ºF (40°C) EAT & 2400ft 3 /m (68m 3 /m)
20.5 kW (5.8 tons)
Conditions
55°F (13°C) entering fluid temperature
50°F (10°C) or lower dew point
Dimensions, inches (mm)
Height, Including Pipe Connections 82-3/8 (2093) 83-1/2 (2121) 80 (2032)
Width With Handles Attached 27-3/8 (695)
Handles Removed 23-1/2 (597)
Depth 6-1/2 (165)
Shipping Length 90 (2286)
Shipping Width 30-1/2 (775)
Shipping Depth 15-1/2 (394)
Max Shipping Depth (4 modules) 62 (1575)
Weight, lb (kg)
Module Only 130 (59) 133 (60) 130 (59)
Shipping 225 (103) 228 (104) 225 (103)
Pipe Connections
Refrigerant Supply 1/2" OD Type ACR
Refrigerant Return 7/8" OD Type ACR
Exterior Finish Black Matte, Heat-Fused Powder Coat
Safety CSA, CE Approved
* Refer to Figure 2 for the complete part number.
Table 7 Rack mounting kit
Rack Part #
Knurr Miracel 198163G1
Dell PowerEdge 4210 199050G1
HP 10642 199051G1
APC AR3100 199054G1
Table 8 Liebert XD Flex Pipe one-shot assemblies, supply and return
Description
Length
ft (m)
Liebert P/N
Straight Connection
Assembly
Liebert P/N
90-Degree
Connection Assembly
Minimum Bend Radius
in (mm)
Supply Return
Liebert XD
Flex Pipe Kit
10 (3.0) 186566G2 186565G2
7 (178) 9 (229)
8 (2.5) 186566G3 186565G3
6 (1.8) 186566G1 186565G1
4 (1.2) 186566G4 186565G4
Table 9 Liebert XD Flex Pipe removable assemblies, supply and return
Description
Length
ft (m)
Liebert P/N
Straight Connection
Assembly
Liebert P/N
90-Degree Connection
Assembly
Minimum Bend Radius
in (mm)
Supply Return
Liebert XD
Flex Pipe Kit
10 (3.0) 187865G2 187864G2
7 (178) 9 (229)
8 (2.5) 187865G3 187864G3
6 (1.8) 187865G1 187864G1
4 (1.2) 187865G4 187864G4
