Specifications
• Hydraulic Oil Type: Use Exmark Premium Hydro
oil.
• Hydraulic Oil Capacity: 4.0 qt. (3.8 L)
• Hydraulic Filter: Replaceable cartridge type.
– Summer use above 32°F (0°C):
P/N 109-0071: 25 microns, 10 psi bypass
– Winter use below 32°F (0°C):
P/N 1-523541: 40 microns, 18 psi bypass
• Speeds:
– 0-7.0 mph (11.3 km/hr) forward.
– 0-5.5 mph (8.6 km/hr) reverse.
• Drive wheel release valves allow machine to be
moved when engine is not running.
Tires & Wheels
Drive Front
Caster Rear Caster
Pneumatic
(Air-Filled) Semi-
Pneumatic Semi-
Pneumatic
Quantity 2 2 1
Tread “Multi-Trac
C/S” Smooth Smooth
Size 18 x
10.50-10 8 x 3.00-4 13 x 8.00-6
Ply Rating 4
Pressure 15 psi (103
kPa)
Cutting Deck
(Sold separately)
• Model Numbers:
– CD42CD
– CD48CD
• Cutting Width:
– 42 inch Deck: 42 inch (106.7 cm)
– 48 inch Deck: 48 inch (121.9 cm)
• Discharge: Center
• Blade Size: (2 ea.)
– w/42 inch Deck: 22.00 inches (55.9 cm)
– w/48 inch Deck: 25.00 inches (63.5 cm)
• Deck Drive:
– Clutching belt on horizontal engine shaft.
Dual “A” section hexagon belt with spring
tensioned idler to jackshaft and blower.
– Heavy-duty cast iron, spiral bevel gearbox is
final drive to blades.
• Deck:
Full floating deck is attached to out-front support
frame. Deck design allows for bagging or
mulching.
• Deck Depth:
– 42 inch Deck: 4 5/8 inches (11.7 cm)
– 48 inch Deck: 4 5/8 inches (11.7 cm)
Dimensions
Overall Width:
Without Deck 42 inch Deck 48 inch Deck
42.6 inches
(108.2 cm) 43.2 inches
(109.7 cm) 49.2 inches
(125.0 cm)
Overall Length:
Without Deck 42 inch Deck 48 inch Deck
67.3 inches
(170.9 cm) 91.8 inches
(233.2 cm) 94.5 inches
(240.0 cm)
Overall Height:
Without Deck 42 inch Deck 48 inch Deck
51.2 inches
(130.0 cm) 51.2 inches
(130.0 cm) 51.2 inches
(130.0 cm)
Tread Width: (Center to Center of
Tires, Widthwise)
42 inch Deck 48 inch Deck
Drive Wheels 32.7 inches
(83.1 cm) 32.7 inches
(83.1 cm)
Wheel Base: (Center of Drive Wheel
to Center of Rear Caster Wheel)
42 inch Deck 48 inch Deck
44.2 inches (112.3 cm) 44.2 inches (112.3 cm)
