SRM-2400/2410
KEY PART NUMBER QTY DESCRIPTION REMARKS
REVISED 09/99
1 10101109560 1 CYLINDER S/N 001001 - 161628
1 10101108960 1 CYLINDER S/N 161629 & UP
2 90016205022 2 BOLT, H.S. 5X22
*3 10101044332 1 GASKET, CYLINDER BASE SEE GASKET KIT PAGE 7
4 10000009562 1 PISTON KIT INCLUDES ITEMS 5 - 8
5 10001109560 2 RING, PISTON
6 10001311520 1 PIN, PISTON
7 10001504630 2 CIRCLIP, PISTON PIN
8 10001411520 2 SPACER, PISTON PIN
9 10001251230 1 BEARING, NEEDLE
10 ------------------- 1 CRANKCASE KIT INCLUDES ITEMS 11 - 15 (USE SB1027)
11 10021242030 2 OILSEAL
12 10021503930 2 PIN, DOWEL
13 90081036201 2 BEARING, BALL 6201
*14 ------------------ 1 GASKET, CRANKCASE SEE GASKET KIT PAGE 7
15 90016205028 3 BOLT 5X28
16 ------------------- 1 CRANKSHAFT (S/N 001001 - 161628)INCLUDES ITEM 9 (USE SB1027)
16 ------------------- 1 CRANKSHAFT (S/N 161629 & UP) INCLUDES ITEM 9 (USE SB1027)
17 10151149230 1 COVER, FAN S/N 001001 - 065999
17 10150352130 1 COVER ASY, FAN S/N 066000 - 117016
17 10150352131 1 COVER ASY, FAN S/N 117017 & UP
18 90016204016 6 BOLT 4X16
19 17500549230 1 DRUM, CLUTCH S/N 001001 - 016000
19 17500548930 1 DRUM, CLUTCH S/N 016001 & UP
20 90070200028 1 CIRCLIP 28
21 90080706001 2 BEARING, BALL 6001
22 90070100012 1 CIRCLIP 12
23 61022349230 1 FLANGE, DRIVE SHAFT HOUSING S/N 001001 - 065999
24 90023805016 4 SCREW 5X16
25 61091027832 1 CUSHION S/N 001001 - 117016
25 61091055230 1 CUSHION S/N 117017 & UP
26 61090327432 1 HOLDER KIT (S/N 001001 - 117016) INCLUDES ITEMS 27 - 29
26 61090355230 1 HOLDER KIT (S/N 117017 & UP) INCLUDES ITEMS 27 - 29
27 90014205025 2 BOLT 5X25
28 61092227432 1 HOLDER
29 61092327432 1 HOLDER (S/N 001001 - 117016)
29 61092355230 1 HOLDER (S/N 117017 & UP)
30 89011552130 1 LABEL, MODEL
31 10151448730 1 COVER, CYLINDER S/N 001001 - 015999
31 10151452630 1 COVER, CYLINDER S/N 016000 - 161628
31 10151448930 1 COVER, CYLINDER S/N 161629 & UP
32 15991254130 1 GUARD, TOP
33 90023805016 1 SCREW 5X16
ENGINE REPOWER
SB1027 1 SHORT BLOCK INCLUDES FACTORY ASSEMBLED
CYLINDER, CRANKCASE, PISTON,
CRANKSHAFT, BEARINGS & SEALS
90051 1 REPOWER TUNE-UP KIT S/N 016001 - 102000 INCLUDES THE FOLLOWING
13031052130 1 FILTER, AIR
13120507320 1 STRAINER, FUEL
13130040630 1 VENT ASY
13201013930 1 PIPE, FUEL
15901010630 1 PLUG, SPARK
99988800079M 1 GD OIL, 1 GAL. MIX
ENGINE/EXTERNAL, INTERNAL, CRANKCASE, FAN HOUSING, COVER
